YS-65XAK三邊封高速顆粒包裝機

特點：

1、適用于食品、醫藥、化工、化妝品行業中顆粒、粉劑、液體、醬料等物品的計量包裝。

The machine is suitable for the measurement and packaging of particles, powders, liquids and sauces in food,medicine, chemical and cosmetics industries.

2、可自動完成制袋、計量、下料、封合、分切、計數，可根據客戶要求配置打印批號等功能。

     All the works of bag making,measuring, filling,sealing, cutting and counting can be done automatically,at the same  time,it can also according to the demand of customers printing batch number and other functions.

3、觸摸屏操作，PLC控制，伺服電機控制袋長，性能穩定、調整方便、檢測準確。智能式溫控儀，PID調節，保證將溫度的誤差控制在1℃內。

     The touch screen operation, PLC contro,servo motor to control the bag length,stable performance,  easy to adjust and accurate detection.Choose the intelligent temperature controller and PID control to ensure the error range of temperature controlled within 1 degree Centigrade.

4、包裝材料：聚丙烯/聚乙烯，鋁箔/聚乙烯，滌綸/鍍鋁/聚乙烯，增強型聚乙烯，紙/聚乙烯等。

Packing material：BOPP/Polyethylene,Aluminium/Polyethylene, Paper/Polyethylene,

Polyester/Aluminizer/Polyethylene and so on. 

技術參數：

計量范圍：1 - 100 g

Measuring Scope

制袋尺寸：長 ( L )  :  30 - 180 mm

Bag Size   寬 ( W )  :  20 - 75 mm

包裝速度：80 - 130 bags / min

Packing Speed

外型尺寸：800 * 1210 * 1950 mm

Dimension ( L * W * H )

整機重量：245kg

Weight

總 功 率：AC220V / 50 - 60Hz / 2.35kw

Total Power

氣       源：≥0.6Mpa

Gas source
